Duratron T4301
Duratron T4301 PAI is a graphite-filled polyamide-imide offers a very low expansion rate and coefficient of friction, exhibiting little to no stick-slip. The addition of PTFE and graphite provides higher wear resistance compared to the unfilled Duratron T4203 PAI grade, and also gives Duratron T4301 PAI excellent dimensional stability capabilities over a wide temperature range. Duratron T4301 PAI's flexural modulus of 1,000,000PSI is higher than most other advanced engineering plastics, which allows it to excel in severe service wear applications such as non-lubricated bearings, seals, bearing cages, and reciprocating compressor parts.
Product Specifications
- Minimum Operating Temperature
- -20°C
- Maximum Operating Temperature
- 250°C
- Food Grade
- No
- Drinking Water Approved
- No
- Tensile Strength (MPa)
- 110
- Thermal Expansion (µm/m.K)
- 35
- Coefficient of Friction
- 0.25
- Chemical Resistance
- Medium
- Formats Available
- Rod, Sheet
